MERRICK Genetix - Outputs; Analog out 1

Page 60 of 104
Outputs
(Main Menu > Advanced Setup > Analog I/O > Outputs)
Selecting Outputs from the Analog I/O menu will present you with the following menu:
Analog Out 1… ↑
Analog Out 2...
Analog Out 3...
Analog Out 4...
Analog Out 5...
Analog Out 6... ↓
Analog Out 1
Selection of one of the Analog Outputs above will allow the following settings to be
configured:
Function… ↑
Numeric Data…
↓
Function
This setting allows you to what process value will be transmitted by this
physical analog output. The options are:
Belt Spd Demand ↑
Feedrate
Belt Load
Belt Speed
Setpoint
Available
Always Zero ↓
