Tachos
(Main Menu > Advanced Setup > Tachos)
Selecting this menu item, you will be presented with the following menu:
Function… ↑
Tacho 1
Tacho 2
Numeric Data… ↓
Note: Not all menu items will appear, depending on how many Tachos are configured
(see Main Menu > Advanced Setup > Configuration).
Function
This setting describes the functionality of the tacho or tachos, if more than one is
configured. The available options are:
First Only ↑
Second Only
First (Pri) Second (Slip)
Second (Pri) First (Slip)
First (Pri) Second (ZSpd)
Second (Pri) First (ZSpd)
Analog Input
From Network
Simulator
None ↓
First Only
This is the setting to use if you have only one tacho connected and it is
connected to the Tacho 1 port on the GCM. This is the tacho that will be used
for all functions within the controller. Note: This tacho may be a 2-channel (i.e.
quadrature), but it is still considered one tacho.
Note: The Configuration settings should bet set to enable only Tacho 1 (see
Main Menu > Advanced Setup > Configuration > Tacho 1).
