Feedrate ↑
Speed
Load
Grand Total
Sub-Total
Belt Spd Demand
Time
Setpoint ↓
Lower
(Main Menu > Display Settings)
This item allows you to select what variable is displayed on the lower line of the main
screen. You may select from the same list as above.
Note: While at the main screen, it is also possible to scroll the lower display through
the available options with the Up/Down arrow keys. This allows you to quickly
observe different data. Whichever display option you last scroll to will remain the
selection for the lower display until you change it, either by scrolling or through the
Display Settings menu as described above.
Damping
These parameters allow you to “damp” (i.e. “smooth) the displayed values, causing
the display to be more stable and therefore more readable. The variables that may
thus be damped are selectable from the following list:
Feedrate ↑
Speed
Load ↓
The Speed and Load damping parameters are settable from 0 to 100, where 0 is no
damping, and 100 is maximum. Note: Damping is not linear, so a setting of 10 is
much greater than 1, and should usually be sufficient. Too much damping will cause
the display to respond so slowly that process changes may not be visible.
Feedrate damping is settable from 1 to 33, and behaves more linearly.
Damping affects the specific displayed value, and the value presented as an Analog
output (if configured), but does not affect the process.
