Page 100 of 104
Appendix B
Logical Outputs
This is a list of all Logical outputs that are available in the Genetix controller.
Note: Its possible some outputs will not be visible, depending on the Configuration
settings (see Main Menu > Advanced Setup > Configuration).
The following Logical outputs are always available, regardless of Configuration
settings.
Name Description
Warning Warning
Fault Fault
Running Feeder belt is running
Feeding There is a feedrate
Ready Feeder is running or startable
LoadCell 1 Ovl Load Cell A/D channel 1 overload
LoadCell 1 Undl Load Cell A/D channel 1 underload
LoadCell 2 Ovl Load Cell A/D channel 2 overload
LoadCell 2 Undl Load Cell A/D channel 2 underload
LC Ch1 Failure Load cell A/D channel 1 failure
LC Ch2 Failure Load cell A/D channel 2 failure
High Belt Load High Belt Load limit
Low Belt Load Low Belt Load limit
High Belt Speed High Belt Speed limit
Low Belt Speed Low Belt Speed limit
High Feedrate High Feedrate limit
Low Feedrate Low Feedrate limit
Load Imbalance Load Cell A/D channels imbalance
Zero Track Fail Zero Tracking has stepped out of range
Belt Slippage The tacho ratio Tac2/Tac1 is outside of its limits
Inferred Load Inferred load used
Inferred Speed Inferred speed used
No Belt Motion No belt motion was detected. Note, this output always active.
Cal in Progress A Calibration procedure is active
HeartBeat Application integrity toggle output
Parameter Fail Parameter load at start-up failed or save after change failed
Port 0 Timeout Communications time out, port 0 (USB)
Port 1 Timeout Communications time out, port 1 (UART0)
Port 2 Timeout Communications time out, port 0 (UART1)
Expansion Board related. Present when one or more expansion I/O boards are
enabled (see Main Menu > Advanced Setup > Configuration ).
XIO 1 Failure Expansion board 1 is enabled and is failing
XIO 2 Failure Expansion board 2 is enabled and is failing
XADC Failure
Analog I/O expansion board is enabled and is and is failing.
(Can be either of two Expansion Analog Cards)
XDC Failure Communication board is enabled and is failing
