Page 99 of 104
Discharge Pluggage Switch related. Present when “Discharge Monitor” is enabled
(see Main Menu > Advanced Setup > Configuration > Discharge Monitor).
Disch Monitor Discharge Pluggage detected
Material On Belt Switch related. Present when “Material on Belt Sw” is enabled
(see Main Menu > Advanced Setup > Configuration > Material on Belt Sw).
Material On Blt There is material on the belt
Flow monitor related. Present when “Infeed Flow Monitor” is enabled (see Main
Menu > Advanced Setup > Configuration > Infeed Flow Monitor).
Low Infeed Flow Low Infeed flow detected
Drive Check related. Present when “Drive Feedback” is enabled (see Main Menu >
Advanced Setup > Configuration > Drive Feedback).
Belt Drive AtSp Belt drive at desired speed
Belt Drv Overld Belt drive overload
Belt Tracking switches related. Present when “Belt Tracking Sws” is enabled (see
Main Menu > Advanced Setup > Configuration > Belt Tracking Sws).
Belt Offs Left Belt tracking Left, first stage
Belt Offs Right Belt tracking Right, first stage
Belt Err Left Belt tracking Left, second stage
Belt Err Right Belt tracking Right, second stage
