Inputs
(Main Menu > Advanced Setup > Analog I/O > Inputs)
Selecting Inputs from the Analog I/O menu will present you with the following menu:
Analog In 1… ↑
Analog In 2…
Analog In 3… ↓
Analog In 1
Selection of one of the Analog Inputs above will allow the following settings to be
configured:
Function… ↑
Calibration…
Numeric Data… ↓
Function
This setting allows you to what process value will be received by this physical
input. The options are:
Feedrate SP ↑
Speed SP
Oloop SP
Load
Speed
Inclination
Available ↓
