Appendix A
Logical Inputs
This is a list of all Logical inputs that are available in the Genetix controller.
Note: Not all inputs will be visible, depending on the Configuration settings (see Main
Menu > Advanced Setup > Configuration).
The following Logical inputs are always available, regardless of Configuration
settings.
Name Description
Belt is Running
Belt is running input.
Total Enabled
Enable grand total update
Subtot Enabled
Enable sub total or volumetric total update
EMT Enabled
Enable EMT total update
Reset Faults
Reset Faults
Reset Warnings
Reset warnings
Reset Subtotal Clear the active subtotal. If in “Bypassed”, will clear the
Volumetric Sub-total.
Spd Pulse Block
Hold input for speed span test
Permit Calibr
Calibration procedures permitted
Diverter Valve
Diverter valve limit switch. ON when valve is open
Register Access
Extended register access permitted
Zero Tracking
Enable zero tracking
External Fault External switch that can be used for indication of fault, and trip
(stop) feeder.
Goto Volumetric
Go into volumetric (inferred load) mode.
Feeder related inputs. Present when “Feeder Control” is enabled (see Main Menu >
Advanced Setup > Configuration > Feeder Control).
Run Permission Controller auto run permission
Netw. Run Perm Controller network run permission
Min Setpoint Revert to Minimum setpoint (feeder control method is Rate or
Speed)
Feeder Block Unconditional feeder block. Feeder will not run in any mode
Local Lockout Block from going out of Auto
Force Network Force Serial Setpoint at good comm’s
Belt Drv Fail Belt Drive Fault or Not Ready output from speed control
Belt Index related. Present when “Belt Index” is enabled (see Main Menu >
Advanced Setup > Configuration > Belt Index).
Belt Index Sw Belt Index Prox Switch
Drag Chain related. Present when “Drag Chain” is enabled (see Main Menu >
Advanced Setup > Configuration > Drag Chain).
Drag Chain ZSS Drag chain zero speed switch
Chn Mot Overld Chain Motor overload
