according to the Calibration of this analog input and the parameters under
Numeric Data (see below).
Note: For automatic angle correction to take place, the “Inclinometer” option
must be enabled (see Main Menu > Advanced Setup > Configuration).
Available
Selecting this parameter allows you to read the analog input via a network or
serial connection. It is not used by the GCM application. The value will
appear in a register in floating point format, which will be scaled according to
the Calibration of this analog input and the parameters under Numeric Data
(see below).
Note, the name of the register used is GLO.AnaInHijack, the number of
which will be dependent on the GCM firmware version. Contact Merrick
Customer Support for assistance if necessary.
Calibration
This menu allows you to calibrate the physical analog input for the signal to
which it is connected. The options are:
Snap Low Current ↑
Snap High Current
↓
Snap Low Current
This allows you to set the GCM for the lowest value that the analog signal
will present. You should be connected to the analog signal and have it
sending its lowest value. If you select this menu item you will go to a screen
that shows the live value of the analog signal. Pressing the Enter key at this
point will accept this value as the input to scale to the low end. You must
press the Enter key again to confirm.
Snap High Current
This allows you to set the GCM for the highest value that the analog signal
will present. You should be connected to the analog signal and have it
sending its highest value. If you select this menu item you will go to a screen
that shows the live value of the analog signal. Pressing the Enter key at this
point will accept this value as the input to scale to the high end. You must
press the Enter key again to confirm.
Numeric Data
This menu contains numeric parameters that allow you to scale the analog
input to the process value it represents. The parameters are:
