Feeder related outputs. Present when “Feeder Control” is enabled (see Main Menu
> Advanced Setup > Configuration > Feeder Control).
High Deviation Feedrate is higher than max deviation limit
Low Deviation Feedrate is lower than max deviation limit
High Setpoint High Setpoint limit
Low Setpoint Low Setpoint limit
High PID CV PID controller output at high limit
Low PID CV PID controller output at low limit
Good Feedrate Good feedrate maintained
Belt Motor Belt to go any direction
Belt Forward Belt to go forward direction
Belt Reverse Belt to go reverse direction
Auto State Feeder state is auto
Manual State Feeder state is manual
Rem Ana Setpnt Remote Setpoint
In Control Ready/runperm/no cal proc
Belt Drive Fail Drive fault or not ready when required
Belt Index related. Present when “Belt Index” is enabled (see Main Menu >
Advanced Setup > Configuration > Belt Index).
Missed Belt Idx Belt Position index not present when expected
Drag Chain related. Present when “Drag Chain” is enabled (see Main Menu >
Advanced Setup > Configuration > Drag Chain).
Chain Motor Drag Chain to go any direction
Chain Forward Drag Chain to go forward direction
Chain Reverse Drag Chain to go reverse direction
Drag Chain Jam Drag Chain zero speed switch time expired
Discharge Pluggage Switch related. Present when “Discharge Monitor” is enabled
(see Main Menu > Advanced Setup > Configuration > Discharge Monitor).
Disch Plugged On when a discharge plugged condition has existed longer then
the delay setting (see Main Menu > Advanced Setup > Feeder
Peripherals > Discharge Monitor > Numeric Data ). Feeder must
be in Auto and must be running.
Material on Belt Switch related. Present when “Material on Belt SW” is enabled
(see Main Menu > Advanced Setup > Configuration > Material on Belt SW).
No Material On when a no material on belt condition has existed longer then
the delay setting (see Main Menu > Advanced Setup > Feeder
Peripherals > Material on Belt SW > Numeric Data ). Feeder
must be in Auto and must be running.
Infeed Flow Monitor related. Present when “Infeed Flow Monitor” is enabled (see
Main Menu > Advanced Setup > Configuration > Infeed Flow Monitor).
No Flow
On when a loss of flow condition has existed longer then the
delay setting (see Main Menu > Advanced Setup > Feeder
Peripherals > Infeed Flow Monitor > Numeric Data ). Feeder
must be in Auto and must be running.
Empty Pipe
On when a calculated loss of material is greater than the
allowable loss (see Main Menu > Advanced Setup > Feeder
