MM-IM User Guide
57
If no points are created in Straton with these names, the dialout test functionality will be
disabled.
Last Dialout Connection
The index of the last attempted connection is reported using a specifically named point:
RES_LAST_DIAL_IN_CONN
3
Connection
Name
Straton Type
Embed Profile
0
CFG_TEST_FREQ_IP_0
REAL
MEDINA_AI
1
CFG_TEST_FREQ_IP_1
REAL
MEDINA_AI
2
CFG_TEST_FREQ_IP_2
REAL
MEDINA_AI
3
CFG_TEST_FREQ_IP_3
REAL
MEDINA_AI
4
CFG_TEST_FREQ_IP_4
REAL
MEDINA_AI
5
CFG_TEST_FREQ_IP_5
REAL
MEDINA_AI
6
CFG_TEST_FREQ_IP_6
REAL
MEDINA_AI
7
CFG_TEST_FREQ_IP_7
REAL
MEDINA_AI
8
CFG_TEST_FREQ_IP_8
REAL
MEDINA_AI
9
CFG_TEST_FREQ_IP_9
REAL
MEDINA_AI
10
CFG_TEST_FREQ_PSTN_0
REAL
MEDINA_AI
11
CFG_TEST_FREQ_PSTN_1
REAL
MEDINA_AI
12
CFG_TEST_FREQ_PSTN_2
REAL
MEDINA_AI
13
CFG_TEST_FREQ_PSTN_3
REAL
MEDINA_AI
14
CFG_TEST_FREQ_PSTN_4
REAL
MEDINA_AI
15
CFG_TEST_FREQ_PSTN_5
REAL
MEDINA_AI
16
CFG_TEST_FREQ_PSTN_6
REAL
MEDINA_AI
17
CFG_TEST_FREQ_PSTN_7
REAL
MEDINA_AI
Name
Straton Type
Embed Profile
RES_LAST_DIAL_IN_CONN
REAL
MEDINA_AO
3
It is named Dial in from the perspective of the master, not the MM-IM
