Metasphere MM-IM - Dsm.cfg; Pulse.dat; Scale.dat

MM-IM User Guide
79
2
172.16.3.2:21007
172.16.3.3:21006
Dsm.cfg
Dsm.cfg has a similar format to medina.cfg. It is used to configure the Data Sharing
Manager on the MM-IM. It defines all points on remote outstations connected to the MM-
IM that are to be read or written, and the points on the MM-IM that they are going to be
read from or written to.
RO
{
[6]=
{
RL=S2;
}
}
RP
{
[6]=
{
=d0000000;
=p0000000;
=a0000000;
=D0000010;
=P0000010;
=A0000010;
}
}
LP
{
[6]=
{
=d0640640;
=D0650650;
=a0640640;
=A0650650;
=p0640640;
}
}
pulse.dat
Pulse.dat contains the configured rollover values for each of the integrated inputs on the
MM-IM. Each line contains the point ID, and the maximum value the point will reach
before rolling over.
PI0 32767
PI1 32767
PI2 32767
PI32 65535
PID1 999
PID2 999
PID3 32767
PID20 32767
Scale.dat
Scale.dat contains the scaling factors for each analogue point used on the MM-IM. These
factors are obtained from the scaling factors embedded in the Straton project, obtained
from the ODF. For each point it gives a multiplier and an offset.
AI25 0.025000 0.00000
AID11 0.012500 0.00000
