MM-IM User Guide
65
RJ45 Pin
9-Way D-Sub male
5
2
6
3
7
-
8
-
For connection to Wago/Beckhoff I/O (RS485)
RJ45 Pin
9-Way D-Sub male
1
3
2
8
3
3
4
5
5
-
6
8
7
-
8
-
For standard male RS232 port (e.g. for connection to modem or radio (RS232)
RJ45 Pin
9-Way D-Sub male
1
6
2
1
3
4
4
5
5
2
6
3
7
8
8
7
