Controller / User Interface | 4-11
3. Choose the communications information:
Settings
Port
Select the computer COM port used to communicate with the
analyzer. See also “Digital Communication” in Chapter 3.
To set up the analyzer to communicate via the Remote Service Port,
configure the settings on the Device Communication tab first, then
return to this dialog box and select RS-485 Port.
Baud Rate
Baud rate at which data will be transferred (fixed at 9600).
Port Type
Select RS-232 if using the analyzer’s Local Service Port.
Select RS-485 if using the analyzer’s Remote Service Port.
Configure the RS-485 port in the Device Communication tab
before selecting RS-485 here.
Address
If the RS-485 port is selected, enter the communications ad-
dress of the analyzer. If using multiple analyzers, enter a differ-
ent address for each unit.
4. Click OK to initialize communication with the analyzer. The software
will revert back to the M933 Properties dialog box and the analyzer
will be Online, as indicated in the Status message box.
If the computer cannot establish communication with the analyzer, see
“Configurator Software Troubleshooting” in this chapter to correct the
problem.
5. View the Status tab. Live data should begin updating within 10 sec-
onds.
NOTE
NOTE
