4-26 | Model 933 UV Analyzer
Measuring Cell Temperature Control
The Measuring Cell operating temperature parameter is monitored and
used to calculate the analyzer results.
This analyzer only monitors (does not control) the Measuring Cell
temperature. Therefore, the Measuring Cell Setpoint must be set to
‘0’.
If the Measuring Cell temperature falls below its Too Cold Setpoint or
exceeds its Too Hot Setpoint, the “Warning Cell Temp” alarm will be trig-
gered and displayed in the software.
The typical (default) Measuring Cell temperature measuring range is “A”
(see chart below).
Measuring Cell Temperature Measuring Range Chart
(JP300, Micro-Interface board)
Temperature
Range Jumper Position Measuring Range
A (default) 1-2 -3 °C to 65 °C
Other ranges are available but AMETEK does not recommend chang-
ing the range or the jumpers.
NOTE
Status (tab)
<<Error Condition>>
NOTE
