Maintaining the flow cell stage
55
Maintaining the flow cell stage
Overview of flow cell stage
1
4
2 3
1
Figure 21 Flow cell stage
No. Name No. Name
1 Sealing gasket 3 Vacuum inlet
2 Aluminum chuck 4 Vacuum adsorption slot
1
1
1
2
Figure 22 Front view of the flow cell
No. Name
1 Alignment hole
