Appendix | Factory Settings
thermoMETER CTL
A 2 Factory Settings
The devices have following presettings at time of delivery:
Signal output object temperature 0 - 5 V
Emissivity 0.970 (1,000 at CTLM)
Transmissivity 1.000
Average time (AVG) 0.2 s (LTL); 0.1 (CTLF, CTLC-4, CTLC-2, CTLC-6, CTLG); inactive (CTLM-5, CTLM-1,
CTLM-2, CTLM-3L, CTLM-3H, CTLM-3H1 to -3H3)
Smart Averaging inactive (CTLF: M1, M2, M3 active)
Peak hold (MAX) inactive
Valley hold (MIN) inactive
Smart Averaging means a dynamic average adaptation at high signal edges (Activation via software only).
Model CTL/CTLF M-1L M-1H M-1H1 M-2L M-2H M-2H1 M-3L
Lower limit temperature range [°C] 0 485 650 800 250 385 490 50
Upper limit temperature range [°C] 500 1050 1800 2200 800 1600 2000 375
Lower alarm limit [°C]
(normally closed)
30 600 800 1200 350 500 800 100
Upper alarm limit [°C]
(normally open)
100 900 1400 1600 600 1200 1400 300
Lower limit signal output 0 V
Upper limit signal output 5 V
Temperature unit °C
Ambient temperature
compensation
Sensor temperature probe (output at OUT-AMB: 0-5 V
-20–180 °C;
not available on 1M and 2M models)
Baud rate [kBaud] CTL: 9.6 / M-xL, M-xH: 115/ CTLG: 9.6
Laser inactive
