Page 13
Technical Data
thermoMETER CTL
3.2 Sensor Models
Model Model codes Spectral response Typical applications
CTL -50 to 975 °C 8 - 14 μm Non-metallic surfaces
CTLF -50 to 975 °C 8 - 14 μm Fast processes
CTLM-1 485 to 2200 °C 1 μm Metals and ceramic surfaces
CTLM-2 250 to 2000 °C 1.6 μm Metals and ceramic surfaces
CTLM-3 50 to 1800 °C 2.3 μm Metals and composite materials at low object tempera-
tures (from 50 °C)
CTLG 100 to 1650 °C 5.0 μm Measurement of glass
CTLC-2
200 to 1450 °C
4.24 μm
Through flames and of CO2- / CO- flame gases
CTLC-4 3.9 μm
CTLC-6 4.64 μm
CTLM-05 100 to 2000 °C 525 nm Metals and ceramic surfaces
On the CTLM-1, CTLM-2 and CTLM-3 and CTLG models the whole measuring range is split into three sub
ranges (L, H and H1).
