Mechanical Installation
thermoMETER CTL
6.2 Controller
110 (4.33)
92 (3.62)
4 (.16)
4 (.16)
70 (2.76)
89 (3.50)
max. 120 (4.72)
4
(.16)
4
(.16)
23 (.91)
47 (1.85)
22 (.87)
24
(.94)
30
(1.18)
M12x1.5
23
(.91)
13
(.51)
13 (.51)
Ø4.5
Fig. 4 Dimensions CTL controller
Dimensions in mm, not to scale
