Page 19
Technical Data
thermoMETER CTL
3.5.4 CTLM-5 Model
Model M-5
Temperature range
1
1000/2000 °C
Spectral range 525 nm
Optical resolution 150:1
System accuracy
2 4
±(0.3 % of reading +2 °C)
2
Repeatability
2
±(0.1 % of reading +1 °C)
2
Temperature resolution 0.2 °C
Response time (90 % signal)
3
1 ms
3
Emissivity/ gain
1
0.100…1.100
Transmissivity/ gain
1
0.100…1.100
Signal processing
1
Peak hold, valley hold, average; extended hold function with
threshold and hysteresis
Software
CompactConnect
1) Adjustable via controller or software
2) E = 1, response time 1 s; ambient temperature 23 ±5 °C
3) With dynamic adaptation at low signal levels
4) Accuracy for thermocouple output: ±2,5 °C or ±1 %
