Page 21
Technical Data
thermoMETER CTL
3.5.6 CTLG Models
Model G-L G-H GF-H
Temperature range
1
100 ... 1200 °C
250 ... 1650 °C 200 ... 1450 °C
Spectral range 5.0 μm
Optical resolution 45:1 70:1 45:1
System accuracy
2 3
±1 °C or ±1.5 %
Repeatability
2
±0.5 °C or ±0.5 %
Temperature range (NETD) 0.1 °C
Exposure time (90 % signal) 120 ms 80 ms
Warm-up time 10 min
Emissivity/ Gain
1
0.100 … 1.100 (adjustable via programming keys or software)
Transmissivity
1
0.100 … 1.100 (adjustable via programming keys or software)
Signal processing Average, peak hold, valley hold
(adjustable via programming keys or software)
Software
CompactConnect
1) Adjustable via controller or software
2) At
ambient temperature 23 ±5 °C; whichever is greater.
3) Accuracy for thermocouple output: ±2,5 °C or ±1 %
