Page 14
Technical Data
thermoMETER CTL
3.3 General Specifications
Sensor Controller
Protection class IP 65 (NEMA-4)
Ambient temperature
1)
-20 ... +85 °C (-4 ... +185 °F) (-20) 0 ... +85 °C
-4 (+32 °F ... +185 °F)
2
Storage temperature -40 ... +85 °C (-4 ... +185 °F)
Relative humidity 10 ... 95 %, non condensing
Material Stainless steel Zinc, cast
Dimensions 100 mm x 50 mm, M48x1.5 89 mm x 70 mm x 30 mm
Weight 600 g 420 g
Cable length 3 m (standard), 8 m, 15 m
Cable diameter 5 mm
Ambient temperature cable max. 105 °C (High temperature cable (optional): 180 °C)
Vibration IEC 68-2-6: 3 g, 11 – 200 Hz, any axis
Shock IEC 68-2-27: 50 g, 11 ms, any axis
Electromagnetic
compatibility (EMC)
EN 61326-1: 2006 / EN 61326-2-3: 2006 / EN 61010-1: 2010
1) Laser will turn off automatically at ambient temperatures > 50 °C.
2) Bei Temperaturen < 0 °C ist die Funktion des Displays nicht mehr gewährleistet.
