Technical Data
thermoMETER CTL
3.5.5 CTLC Models
Model C-2
6
C-4
6
C-6
6
Temperature range
1
200/1450 °C
Spectral range 4.24 μm 3.9 μm 4.64 μm
Optical resolution 45:1
System accuracy
3 4 5
±1 %
Repeatability
3
±0.5 % or ±0.5 °C
Temperature resolution (digital) 0.1 °C
Response time (90 % signal)
2
10 ms
Emissivity/ gain
1
0.100…1.100
Transmissivity/ gain
1
0.100…1.100
Signal processing
1
Peak hold, valley hold, average;
extended hold function with threshold and hysteresis
Software
CompactConnect
1) Adjustable via programming keys or software
2) With dynamic adaptation at low signal levels
3) At ambient temperature 23 ±0.5 °C; whichever is greater; temperature of the object ≥ 0 °C
4) e = 1, response time 1 s
5) Accuracy for thermocouple output: ±2,5 °C or ±1 %
6) Models C-2, C-4, C-6 also known as H-models with 400 ... 1650 °C.
