Technical Data
thermoMETER CTL
3.5.3 CTLM-3 Models
Model M-3L M-3H M-3H1 M-3H2 M-3H3
Temperature range (scalable)
1 2
50/400 °C 100/600 °C 150/1000 °C 200/1500 °C 250/1800 °C
Spectral range
2.3 μm
Optical resolution
60:1 100:1 300:1
System accuracy
3 5
±(0.3 % of reading +2 °C)
3
Repeatability
3
±(0.1 % of reading +1 °C)
3
Temperature resolution (digital) 0.1 °C
Exposure time (90 % signal)
4
1 ms
4
Emissivity/ Gain
1
0.100…1.100 (adjustable via programming keys or software)
Transmissivity/ Gain
1
0.100…1.100 (adjustable via programming keys or software)
Signal processing
1
Average, peak hold, valley hold
(adjustable via programming keys or software)
Software
CompactConnect
1) Adjustable via controller or software
2) Target temperature > sensor temperature +25 °C
3) E = 1, response time 1 s; ambient temperature 23 ±5 °C
4) With dynamic adaptation at low signal levels
5) Accuracy for thermocouple output: ±2,5 °C or ±1 %
