Technical Data
thermoMETER CTL
3.5.2 CTLM-1 and CTLM-2 Models
Model M-1L M-1H M-1H1 M-2L M-2H M-2H1
Temperature range (scalable) 485/1050 °C 650/1800 °C 800/2200 °C 250/800 °C 385/1600 °C 490/2000 °C
Spectral range 1 μm 1.6 μm
Optical resolution 150:1 300:1 150:1 300:1
System accuracy
1 2
±(0.3 % T of reading +2 °C)
3
Repeatability
1
±(0.1 % T of reading +1 °C)
3
Temperature resolution (NETD) 0.1 °C
Exposure time (90 % signal) 1 ms
4
Emissivity/ Gain 0.100 … 1.100 (adjustable via programming keys or software)
Transmissivity 0.100 … 1.100 (adjustable via programming keys or software)
Signal processing Average, peak hold, valley hold
(adjustable via programming keys or software)
Software CompactConnect
1) At ambient temperature 23 ±5 °C; whichever is greater.
2) Accuracy for thermocouple output: ±2,5 °C or ±1 %
3) e = 1/ Response time 1 s
4) With dynamic adaptation at low signal levels
