 Handler I/O Pin Description:
Pin
Pin Name
I/O
Function
1
/START
I
Test Trigger
2
/ DAV
O
Test Program Ended
3
/PASS
O
Test Result is PASS
4
/FAIL
O
Test Result is FAIL
5
GND
-
Ground
6
GND
-
Ground
7
GND
-
Ground
8
NULL
-
Empty Pin
9
NULL
-
Empty Pin
10
+5V
-
DC +5V Output
11
NULL
-
Empty Pin
12
NULL
-
Empty Pin
13
/READY
O
Test preparation ready, which means it can receive
trigger status.
(When the measuring program is executing or when in
modes other than Meter Mode and Multi-Step Test
Mode, this signal will not be ready.)
14
/INDEX
O
Measuring program complete (only measurement is
complete; the entire test program has not yet
completed).
15
/OK1
O
When the compare function is enabled in Meter Mode,
the 1st item has passed.
16
/OK2
O
When the compare function is enabled in Meter Mode,
the 2nd item has passed.
17
/OK3
O
When the compare function is enabled in Meter Mode,
the 3rd item has passed.
18
/OK4
O
When the compare function is enabled in Meter Mode,
the 4th item has passed.
19
/NG1
O
When the compare function is enabled in Meter Mode,
the 1st item has failed.
20
/NG2
O
When the compare function is enabled in Meter Mode,
the 2nd item has failed.
21
/NG3
O
When the compare function is enabled in Meter Mode,
the 3rd item has failed.
22
/NG4
O
When the compare function is enabled in Meter Mode,
the 4th item has failed.
23
undefined
O
Reserved
24
undefined
O
Reserved
