3. CT-8700 REMOTE
15-PIN Connector
1 CTL0 9
2 CTL1 10
IPC∅
3 CTL2 11
4 CTL3 12
5 CTL4 13
6 CTL5 14
7 CTL6 15 GND
8 CTL7
IPC∅+GND define as [TEST ] input (short these two pins )
On testing status, the CTL 0, CTL 2, CTL 3, are the output signal which are defined as
bellow:
CTL0 “PASS” status
CTL1 ”FAIL” status
CTL2
CTL3
CTL0 ~ CTL1 Inside circuit diagram listed as following
