6. Remove spool (C0100).
7. Using a 1/4 in internal hex wrench remove plug (C0050) and discard O-ring (C0050A).
8. Use a 5 mm internal hex to remove shuttle valve (C0025).
9. Using a 1/8 in internal hex wrench, remove 3 plugs (C0060) and discard O-rings (C0060A).
10. Using a 3 mm internal hex, remove 2 orifices (E00T3 and E00T2).
Inspection
Inspect the machined surfaces on the control and the endcap. If you find any nicks or scratches, replace
the control or endcap assembly. Check that shuttle ball moves freely in housing (C0025).
Assembly
1. Install orifices (E00T3 and E00T2). Torque to 6 N•m [4 lbf•ft].
2. Lubricate and install new O-rings (C0060A). Using a 1/8 inch internal hex wrench, install and torque
plugs (C0060) to 8 N•m [6 lbf•ft].
3. Lubricate and install spool (C0025) into control block. Using a 5 mm internal hex wrench, torque to 14
N•m [11 lbf•ft]
4. Install new O-ring (C0050A). Using a 1/4 inch internal hex wrench, install and torque plug (C0050) to
40 N•m [30 lbf•ft].
5. Lubricate and install spool (C0100).
6. Lubricate and install new O-ring (B035A).
7. Install solenoid (B0010). Using a 4 mm internal hex wrench. Install screws (B0050). Torque to 6 N•m [4
lbf•ft].
8. Lubricate and install new O-ring (B0025) onto solenoid. Install coil (B0020A). Lubricate and install new
O-ring (B0028) onto solenoid.
9. Install coil nut (B0027) and torque to 3.5 N•m [2.6 lbf•ft] using a 26mm 12-point socket. Do not
overtorque.
Service Manual H1B 060/080/110/160/250 Bent Axis Motors
Minor repair
48 11024924 • Rev CB • February 2015
