9
www.roadwidener.com
Model SPD-6
2.2 operAtors Console
A - Murphy Display
B - Ignition
C - Parking Brake On Indicator
D - Emergency/Park Brake (E-Stop)
E - Travel Speed Controller - Conveyor Speed
F - Brake Pedal
G - Conveyor On/Off
H - Engine Throttle
I - Conveyor Discharge Direction
J - Steering Wheel
K - Murphy Audible Alarm
L - Hydraulic Extension
M - Slope Control
N - Grade Control
O - Drive Speed Range
P - Horn
Q - Lights (Optional)
R - Hazard Lights (Optional)
S - Turn Signals (Optional)
T - Hydraulic Push Roller (Optional)
U - Tool Cylinder (Optional)
V - P.T.O. Speed (Optional)
W - P.T.O. Power (Optional)
13
14
27
41
25
11 10
17
(4) PL
10
26
43
54
4) PL
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
