Model SPD-6
No. Qty. Description Part Number
1 REF Chassis Weldment SP-1905
2 2 Drive Roller, Conv SP-894
3 2 Motor Coupling SP-695
4 2 Wiper Frame SP-694
5 2 Wiper Rubber SP-693
6 2 Wiper Retainer SP-692
7 2 Sideboard Rubber Assy SP-2052
8 1 Weldment, Dribble Gate,
Right
SP-2034
9 1 Deector Assembly, L/S SP-1978
10 1 Cover, Idle End SP-1977
11 1 Weldment, Dribble Gate, Left SP-1975
12 1 Conv. Belt Assy, Roller
Chain
SP-1971
13 2 Retainer Upper Sideboard SP-1927
14 2 Sideboard Rubber SP-1926
15 1 Front Bib SP-1924
16 1 Bib Retainer SP-1923
17 1 Rear Upper Mtg Bckt
Sideboard
SP-1921
18 1 Front Upper Mtg Bckt
Sideboard
SP-1920
19 2 Chain Cover Assy SP-1380
20 1 Deector Assembly SP-1094
21 4 Panel Mount Wldmt, Dribble
Gate
SP-1075
22 25 Roller SA-1147
23 2 Motor, Hydraulic, M5061
24 2 Bearing, Take-Up Sc 2" Bore M0146
25 10 Lock Washer, 5/16 LKW-5/16
26 18 Lock Washer, 3/8 LKW-3/8
27 9 Lock Washer, 1/2 LKW-1/2
28 2 Hex Nut, 5/16-18 UNC HXN-5/16-18
29 6 Hex Nut, 3/8-16 UNC HXN-3/8-16
30 9 Hex Nut, 1/2-13 UNC HXN-1/2-13
31 4 Hex Jam Nut, 3/4-16 UNC HJN-3/4-16
32 8 Hex Hd Cap Screw 5/16-18
UNC X 1
HCS-5/16-18-1.00
33 6 Hex Hd Cap Screw, 3/8-16
UNC X 1 3/4
HCS-3/8-16-1.75
34 12 Hex Hd Cap Screw, 3/8-16
UNC X 1 1/4
HCS-3/8-16-1.25
35 26 Flat Socket Hd Cap Screw
5/16-18 UNC X 1
FCS-5/16-18-1.00
36 19 Flat Socket Hd Cap Screw
5/16-18 UNC X 3/4
FCS-5/16-18-0.75
37 9 Flat Socket Hd Cap Screw
1/2-13 UNC X 2-1/2
FCS-1/2-13-2.50
38 25 Roll Pin 1/8 X 3/4 DR62311
No. Qty. Description Part Number
39 16 Washer Hd Thread Forming
Screw 5/16-18 UNC X 0.50
TFS-5/16-18-0.50
40 4 Square Hd Set Screw 3/4-10
UNC X 4-1/2" Lg
SSS-0.75-10-4.50
41 4 Lube Fitting, Straight,
Serrated
1743-8
42 2 Hex Hd Cap Screw, 1/2-13
UNC X 1 3/4
HCS-1/2-13-1.75
43 4 Hex Jam Nut, 1/2-13 UNC HJN-1/2-13
44 2 Cotter Pin, 1/8 Dia X 1-1/2 CTP-1/8-1.50
