Model SPD-6
No. Qty. Description Part Number
1 1 Column Mount Weldment SP-1981
2 1 Blade Travel Retainer SP-891
3 1 Push Tube (Outer) SP-888
4 1 Push Tube (Inner) SP-887
5 1 Blade Push Anchor SA-902
6 2 Hitch Pin 1/4 X 3 1/2 SA-349-27
7 1 Edger Brace SA-131
8 1 Support Lug SA-109
9 1 Support Pivot SA-108
10 2 Blade Hinge Pin SA-105
11 1 Clip (Outer Edger) SA-104
12 1 Outer Edger SA-102
13 1 Blade Section - 1 Ft SA-097
14 1 Blade Section - 2 Ft SA-096
15 2 Hinge Half (Blade) SA-089
16 1 Hinge Half (Mount) SA-088
17 1 Inner Edge Plate SA-082
18 1 Spreader Tube SA-081
19 1 Blade Mount SA-080
20 1 Column Top SA-077
21 1 Column SA-072
22 1 Hyd Variable Strike Off
Blade Assy (SA) [Option]
SA-1737
23 2 Eyebolt W/ Shoulder 1/2" M6126
24 1 Hitch Pin 5/8" Dia X 3" Lg
Class III
M6105
25 1 Ball Mount 2" Class III M6104
26 2 Hairpin, Cotter, 0.120 Wire
X 2 3/8
M11024
27 8 Hair Pin, Cotter, 0.178 Wire
X 3 9/16
M11013
28 1 Hitch Pin 3/4 X 4 3/4 M11006
29 2 Ball Hitch, 2 Dia, Zinc-
Plated
M11005
30 1 Slope Cylinder (Sae-9030)
2 X 30
M1019
31 1 Cylinder, Hydraulic, 3000
PSI, Tie Rod, 2-1/2" X 18",
M1013
32 1 Lock Washer, 3/4 LKW-3/4
33 37 Lock Washer, 1/2 LKW-1/2
34 1 Hex Nut, 3/4-10 UNC HXN-3/4-10
35 37 Hex Nut, 1/2-13 UNC HXN-1/2-13
36 3 Hex Hd Cap Screw, 1/2-13
UNC X 4 1/2
HCS-1/2-13-4.50
37 6 Hex Hd Cap Screw, 1/2-13
Unc X 2
HCS-1/2-13-2.00
38 25 Hex Hd Cap Screw, 1/2-13
Unc X 1 3/4
HCS-1/2-13-1.75
39 2 Hex Hd Cap Screw, 1/2-13
UNC X 1 1/2
HCS-1/2-13-1.50
No. Qty. Description Part Number
40 1 Hex Hd Cap Screw 1-8 UNC
X 7 1/2
HCS-1-8-7.50
41 1 Hex Hd Cap Screw, 1-8
UNC X 5
HCS-1-8-5.00
42 11 Flat Washer, 1/2 FLW-1/2
43 4 Flat Washer, 1 FLW-1
44 2 Elastic Stop Nut, 1-8 UNC ESN-1-8
45 2 Pin, Safety Snap 5/16 X
2-1/2
M6127
46 1 Lube Fitting, Straight,
Serrated
1743-8
