Technical Information
51
CM6
Note:
For reassembly:
The thermostat connects to the white terminal on the grinder (Figure 001-39).
Figure 001-39: Grinder Thermostat Connection
4.12 Grinder Thermostat (F3-3) Removal
See Section 001-4.11.
4.13 EPL Power Electronic (1N1-1, 2N1-1) Removal
1. Remove the top cover; see Section 001-4.5.
2. Remove the side casing; see Section 001-4.6.
3. Remove the T10 screw securing the power electronic assembly (Figure 001-40,
Item 1).
4. Take out the power electronic assembly.
Note:
To avoid connection errors, disconnect wiring harnesses from the old power
electronic and connect them to the new power electronic one at a time.
5. Disconnect wiring harnesses from the old power electronic one at a time.
