Miele CM6 - Chute Present Switch Removal; Pump and Thermostat Removal

Technical Information
52
CM6
Figure 001-40: Power Electronic Screw
4.14 Chute Present Switch (S87-5) Removal
1. Remove the top cover; see Section 001-4.5.
2. Remove the side casing; see Section 001-4.6.
3. Take out the chute present switch (Figure 001-41, Item 1) and disconnect it from
the power electronic.
Figure 001-41: Chute Present Switch
4.15 Pump (M7) with Thermostat (F3-2) Removal
1. Remove the top cover; see Section 001-4.5.
2. Remove the side casing; see Section 001-4.6.
