Technical Information
13
KF 18xx/19xx
030 Cooling Components
1 Technical Data
Temperature Resistance
°F °C kΩ
104 40 2.7
95 35 3.3
86 30 4.0
77 25 5.0
68 20 6.2
59 15 7.9
50 10 10.0
41 5 12.7
32 0 16.3
23 -5 21.2
14 -10 27.8
5 -15 36.5
-4 -20 48.6
-13 -25 65.3
-22 -30 88.7
-31 -35 121.8
-40 -40 169.1
Table 030-1: NTC Resistance Values
R17/5 (
r
efrigerator) R17/4 (
f
reezer)
KF 19xx KF 18xx KF 19xx KF 18xx
Power rating 25W 21W 19W 19W
Resistance 576Ω 686Ω 758Ω 758Ω
Current 0.2A 0.2A 0.16A 0.16A
Table 030-2: Drain Channel Heater Specifications
R17/3 (
r
efrigerator) R17/2 (
f
reezer)
KF 19xx KF 18xx KF 19xx KF 18xx
Power rating 140W 140W 175W 142W
Resistance 103Ω 103Ω 83Ω 101Ω
Current 1.2A 1.2A 1.5A 1.2A
Table 030-3: Defrost Heater Specifications
Water intake
heater (R17/12)
Interior heater,
refrigerator (R17/6)
Refrigerant stop
valve (Y30/1)
Voltage [V] 120 120 120
Power rating [W] 1.9 10 —
Resistance [kΩ] 7.6 1.4 1.33
Current [A] 0.02 0.08 0
Frequency [Hz] 60 60 60
Table 030-4: Other Component Specifications
