Miele KF 19 Vi Series User Manual

Technical Information
73
KF 18xx/19xx
Figure 030-78: RemoteVision Installation, Part 1
2. Remove the cover.
3. Push the module into the slot until it locks into place. See Figure 030-79.
Bend the antenna (Figure 030-79, Item 4) into a vertical/upright position.
Figure 030-79: RemoteVision Installation, Part 2
4.45 Lightbulb Replacement
Note:
Use the main switch to turn the appliance off.
To reduce the risk of electric shock, disconnect the appliance from the
power supply by unplugging or tripping the circuit breaker.
4.45.1 Upper Lighting
1. Grasp the front of the light cover with both hands, and slide it back. See
Figure 030-80.
2. Carefully pull the cover forward and out.
Figure 030-80: Removing the Light Cover
