Technical Information
44
KF 18xx/19xx
Figure 030-28: Lighting Assembly Temperature Monitor
4.11 Removing the Refrigerator Drain Channel & Defrost Heaters
1. Disconnect the appliance from the power supply.
2. Remove the refrigerator evaporator cover; see Section 030-4.6.
3. Remove the refrigerator lighting assembly. See Section 030-4.8.
4. Press in the left and right retaining tabs; pull the heater holder plate
forward and down. See Figure 030-29.
Figure 030-29: Retaining Tabs Holding the Heater Plate
5. Disconnect the defrost heater and drain channel heater connections. See
Figure 030-30, Items 1 and 2.
6. Remove the plate with heaters from the appliance.
7. Remove the appropriate heater(s).
