Technical Information
45
KF 18xx/19xx
Figure 030-30: Defrost & Drain Channel Heater Connections
4.12 Removing Refrigerator Evaporator Temperature Limiter 1F2
1. Disconnect the appliance from the power supply.
2. Remove the refrigerator evaporator cover; see Section 030-4.6.
3. Remove the refrigerator lighting assembly. See Section 030-4.8.
4. Remove the drain channel/defrost heater plate. See Section 030-4.11.
5. Disconnect the temperature limiter electrical connection. See Figure 030-
31, Item 1.
6. Remove the adhesive strips.
7. Cut the cable ties on the temperature limiter.
8. Remove the temperature limiter. See Figure 030-31, Item 2.
