12
a. Setting Indicator h. ‘PROG’ button
b. Total Indicator i. ‘NEXT’ button
c. Alarm Indicator j. ‘DOWN’ button
d. Percentage Indicator k. ‘UP’ button
e. Unit Indicator l. Phase Indicator
f. Capasitive/Inductive Indicator m. Window Indicator
g. Digit Display
4. Display and Buttons
a
b
c
d
e
f
g
h
i
j
k
l
m
