Read or write (Function 0x03,0x04 or 0x06)
Register Description Range
100 PT ratio primary 100~33kV
101 PT ratio secondary 100~250V
102 CT ratio primary 5~9995A
103 CT ratio secondary 5A
104 Interval Demand 60~1800s
105 Sub-Interval Demand 1~120
106 System Confi guration 3P4W/ 3P3W
107 Backlight setting ON/OFF
108 System scroll setting ON/OFF
109 Scroll interval 1-10 secs
110 Neutral setting ON/OFF
111 Minutes 0-59mins
112 Hours 0-23hrs
113 Days 0-9999day
NOTE:
Register list is based on fi rmware version 1.0
Table 8: Setting data register
