Mikro DPM380 - Page 44

38
Read Only (Function 0x03 or 0x04)
Register Description Type
Min.
Unit
Range
4008-
4009
Negative Reactive
Energy
dword 1kVArh 0~1000000M
4010-
4011
Positive Reactive
Energy
dword 1kVArh 0~1000000M
4012-
4013
Total Real Power int 1W -2000M~2000M
4014-
4015
Total Apparent
Power
dword 1VA 0~2000M
4016-
4017
Total Reactive
Power
int 1VAR -2000M~2000M
4018 Total Power Factor word 0.001 0 ~ 1.000
4019 Frequency word 0.01Hz 45.00 ~ 65.00
4020-
4021
Instantaneous
Current L1
dword 0.001A 0~999.9kA
4022-
4023
Instantaneous
Current L2
dword 0.001A 0~999.9kA
4024-
4025
Instantaneous
Current L3
dword 0.001A 0~999.9kA
4026-
4027
Instantaneous
Current Ln
dword 0.001A 0~999.9kA
4028-
4029
Voltage Phase L12 dword 0.1V 0~999.9kV
4030-
4031
Voltage Phase L23 dword 0.1V 0~999.9kV
Table 7: Operation data register (cont)
