15 14 13 12 11 10 9876543210
ALARM - ACKNOWLEDGE
ALARM - ON/OFF
POLL SELECT
C1 C2 C1 C2 COMMAND DESCRIPTION
20 48 20 49 Machine
15 14 13 12 11 10 9876543210
MACHINE - ON/OFF
ON/OFF ALLOWED
ALARM - ACKNOWLEDGE
POLL SELECT
C1 C2 C1 C2 COMMAND DESCRIPTION
20 4A 20 4B Protected mode - machine
POLL SELECT
C1 C2 C1 C2 COMMAND DESCRIPTION
20 70 Temperature to process
20 72 Temperature from process*
20 78 Flow rate from unit GPM*
20 E0 Blanket Poll
Returns: 20 30 Setpoint
20 32 High alarm deviation
20 34 Low alarm deviation
20 40 Status process
20 70 To process temperature
