Miller Multimatic 200 - Specifications

. A complete Parts List is available at www.MillerWelds.com
OM-253392 Page 11
SECTION 4 − SPECIFICATIONS
4-1. Serial Number And Rating Label Location
The serial number and rating information for this product is located on the side. Use rating label to determine input power requirements and/or rated
output. For future reference, write serial number in space provided on back cover of this manual.
4-2. Unit Specifications For MIG (GMAW)
. Do not use information in unit specifications table to determine electrical service requirements. See Sections 5-10, 5-12, and 5-13 for information
on connecting input power.
. This equipment will deliver rated output at an ambient air temperature up to 1045F (405C).
Input
Voltage
Rated Welding
Output
Amperage
Range
Maximum Open-
Circuit Voltage
DC
Amperes Input at Rated
Load Output, 50/60 Hz,
Single-Phase
120 VAC
110 A @ 19.5 Volts DC,
20% Duty Cycle
75 A @ 17.75 Volts DC,
100% Duty Cycle*
30 − 140
90
22.4
14.6*
Wire Type
And Diameter
Solid/Stainless Flux Cored Wire Feed Speed Range
.023 - .035 in.
(0.6 - 0.8 mm)
.030 - .035 in.
(0.8 - 0.9 mm)
70 − 425 IPM (1.75 − 10.8 m/min)
230 VAC
150 A @ 21.5 Volts DC,
20% Duty Cycle
120 A @ 20 Volts DC,
100% Duty Cycle*
30 − 200 90
17.5
13.1*
Wire Type
And Diameter
Solid/Stainless Flux Cored Wire Feed Speed Range
.023 − .035 in.
(0.6 − 0.9 mm)
.030 − .045 in.
(0.8 − 1.2 mm)
70 − 425 IPM (1.75 − 10.8 m/min)
* CSA Rating
4-3. Unit Specifications For TIG (GTAW)
. Do not use information in unit specifications table to determine electrical service requirements. See Sections 5-10, 5-12, and 5-13 for information
on connecting input power.
. This equipment will deliver rated output at an ambient air temperature up to 1045F (405C).
Input
Voltage
Rated Welding
Output
Amperage
Range
Maximum Open-
Circuit Voltage
DC
Amperes Input at Rated
Load Output, 50/60 Hz,
Single-Phase
120 VAC
150 A @ 16 Volts DC,
30% Duty Cycle
70 A @ 13 Volts DC,
100% Duty Cycle*
5 − 150
90
27.0
10.5*
230 VAC
150 A @ 16 Volts DC,
30% Duty Cycle
100 A @ 14 Volts DC,
100% Duty Cycle*
5 − 150 90
13.8
15.9*
* CSA Rating
