7. Press the START key again to adopt the
flashing nominal value of the larger master
as the current setting. The display then re-
turns to the catalog of functions and param-
eters item “MSTR.MAX”.
If at this point either the MASTER or DATA
key is pressed instead of START, the dis-
play returns to the numerical input stage (cf.
point 4). The indicated nominal value can be
changed again if required.
8. Once the nominal value of the larger mas-
ter has been correctly entered and “MSTR.
MAX” is displayed, press MASTER in the
catalog of functions and parameters. MSTR.
MIN” is displayed.
9. Press MENU again.
10. Set the nominal value for the smaller master
as described in section “Changing numerical
values for parameter settings” of Chapter 0.
11. Press the START key to adopt the flashing
nominal value of the smaller master as the
current setting. The display then returns to
the catalog of functions and parameters
item MSTR.MIN”.
If at this point either the MASTER or DATA
key is pressed instead of START, the display
returns to the numerical input stage (cf. point
10). The indicated nominal value can be
changed again if required.
12. If no further settings are to be made in the
catalog of functions and parameters, press
the START key. The standard display ele-
ments appear.
If further settings are necessary, navigate
to the appropriate point of the catalog of
functions and parameters using the ESC,
MASTER, DATA and MENU keys and carry
out the settings as required.
.
