14.6 Examples of interface configuration
14.6.2 Interface configuration for data
transfer to a computer
Data transfer to a computer usually takes place
through dialog, i.e. the computer can use spe-
cific commands to request measured values or
change settings on the instrument. The follow-
ing interface protocols are suitable for this activ-
ity: MARTALK, M1240, OPTORSD, OPTORSS.
On principle, the ASCII interface protocol is
also suitable, however using this setting means
that data transfer can only be initiated from the
Millimar (by pressing the DATA key) and not
from the computer.
PROTOCL: MARTALK,M1240,OPTORSD
OPTORSS, ASCII)
FORMAT: 8N1
HANDSHK: XON/XOF
BAUD: 9600
SEND: AUTOM.
14.6.1 Interface configuration for data
transfer to a printer
MSP2 printer from Mahr
The following settings are recommended when
using the Mahr MSP2 printer:
PROTOCL: M1240
FORMAT: 8N1
HANDSHK: NONE
BAUD: 9600
SEND: MANUAL or AUTOM.
If the setting “MANUAL (4.6.5.1)” is selected un-
der “SEND (4.6.5)”, data is transferred by press-
ing the DATA key on Millimar or on the printer.
ASCII printer from another manufacturer
The following settings are recommended when
using a printer from another manufacturer –
PROTOCL: ASCII
FORMAT: 8N1
HANDSHK: NONE
BAUD: 9600
SEND: MANUAL or AUTOM.
If the setting “MANUAL (4.6.5.1)” is selected un-
der “SEND (4.6.5)”, data is transferred by press-
ing the Millimar DATA key.
