8. Use the DATA and MASTER keys to select
the data flow control mode. The following
control options are available:
NONE The sending and receiving devic-
es are synchronous (i.e. use the
same transfer rate) and therefore
the data flow does not need to
be interrupted.
XON/XOF The sending and receiving de-
vices are asynchronous. The
control signals for interrupting
data transfer are embedded in
the data stream (software hand-
shake) and transferred via the
data line.
RTS/CTS (Request to send/Clear to send)
The sending and receiving de-
vices are asynchronous. The con-
trol signals for interrupting data
transfer are transferred on sepa-
rate control lines and not on the
data line (hardware handshake).
9. Press START once the desired setting is indi-
cated. The setting is adopted and “HANDSHK
(4.6.3)” is displayed again.
10. If no further settings are to be made in the
catalog of functions and parameters, press
the START key. The standard display ele-
ments appear.
If further settings are necessary, navigate
to the appropriate point of the catalog of
functions and parameters using the ESC,
MASTER, DATA and MENU keys and carry
out the settings as required.
14.4 Selecting the transfer rate
Specify the rate (in bits per second) at which
data is to be transferred. The transfer rate (baud
rate) of the devices must be identical.
1. Press the MENU key. The catalog of func-
tions and parameters item “FEATURE (1)” is
displayed.
2. Use the DATA and MASTER keys to select
the setting “SETTING (4)”.
3. Press the MENU key. “DISPLAY (4.1)” is dis-
played.
4. Use the DATA and MASTER keys to select
the setting “COM (4.6)”.
5. Press the MENU key. “PROTOCL (4.6.1)” is
displayed.
6. Use the DATA and MASTER keys to select
“BAUD (4.6.4)”.
7. Press the MENU key. The transfer rate that
was last selected flashes.
8. Use the DATA and MASTER keys to select
the desired transfer rate. The following trans-
fer rates are available: 19,200, 9,600, 4,800,
2,400, 1,200, 600, 38,400.
9. Press START once the desired transfer rate is
displayed. The setting is adopted and “BAUD
(4.6.4)” is displayed again.
10. If no further settings are to be made in the
catalog of functions and parameters, press
the START key. The standard display ele-
ments appear.
If further settings are necessary, navigate
to the appropriate point of the catalog of
functions and parameters using the ESC,
MASTER, DATA and MENU keys and carry
out the settings as required.
