4 Positioning the probe in the measuring device (setup)
5. Move the probe by hand or using a position-
ing device if available, so that the measured
value is zero.
6. Clamp the probe in this position.
7. Press either the ESC or START key to exit
setup mode.
To use a probe to take measurements across the
full measuring range available, it has to be cor-
rectly positioned in the measuring instrument. If
this is not the case, the measuring range can be
exceeded or fallen short of.
1. Insert the probe into the measuring instru-
ment.
2. Fit a setting master or a workpiece of known
size into the measuring instrument.
3. Press the TEST key.
The measured value transmitted by the
probe across channel C1 is depicted on the
scale and in the top line of the numerical dis-
play. If applicable, the bottom line of the nu-
merical display depicts the measured value
transmitted by the probe across C2.
4. If the Millimar display range is too small or
large to allow the probe to be correctly po-
sitioned, it can be changed using the DATA
and MASTER keys. To do this: Press either
the DATA or MASTER key. The current dis-
play range is shown. Press one of the two
keys again to resize the display range in line
with the programmed increments and to
change the analog scale accordingly.
