17 Error messages
Error Routine Possible causes Remedy
OVFLOW
Measurement The probe value exceeds
the measuring or plausibility
range.
Select a larger measuring or
plausibility range.Correct any
probe overmodulation.
OUT LIM
Calibration
The calculated correc-
tion factor is outside
the permissible range.
The specified gage blocks
were not used or the di-
mensions were incorrectly
entered.
The nominal value selector
was incorrectly set.
The probe or nominal value
selector has been connect-
ed to the incorrect input
jack.
ERR RXD
RS232 interface There is a break signal >
700 ms at the RXD input.
Check the connection be-
tween the RS232 interface
and external device (e.g.
computer, printer, program-
mable controller).
FRM FEH
A two-point master mea-
surement was selected
even though a connec-
tion formula including both
probe channels is adjusted.
Two-point master measure-
ments are only possible if
the connection formula set
under “FORMULA (1.3)”
reads either “C1” or “-C1”!
Adjust either “C1” or “-C1”
under “FORMULA (1.3)”.
OVF LCD
The number of digits to be
displayed exeeds the num-
ber of digits the can be indi-
cated on the display.
The indication does not change even
though the bolt of the probe is con-
tinuously moving. The raw values in-
dicated after pressing TEST, however,
are OK.
Under PROCESS -> MEA-
SURE -> MEAS.MOD
(3.1.1), the measur-
ing mode “AUTOM:
(3.1.1.2)” was adjusted.
Adjust the “NORMAL
(3.1.1.1)” measuring
mode, as the case may be.
