Mahr GmbH, Millimar C1208/C1216/1240
0 Initial commissioning
1. Carefully unpack the Millimar, probes, and
power supply unit.
i
Do not dispose of the original packag-
ing. In the case of a complaint or repair,
the appropriate components will need
to be returned to the manufacturer
in the original packaging. Damage
caused during transit when compo-
nents are not suitably packaged is not
covered by the Mahr GmbH warranty!
2. Connect the Millimar to the power supply
using the power supply unit supplied.
i
No other power supply unit should
be used. Damage caused by using
any other power supply unit is not
covered by the Mahr GmbH war-
ranty!
3. Connect the probes to the C1 and/or C2 in-
puts.
i
C 1208 PE units have only one
probe input for pneumatic probes
C 1208/C 1216/C 1240 M, T, F units
have two probe inputs. One induc-
tive probe can be connected to
each input. If only one probe is be-
ing used, this should always be con-
nected to the C1 input.
4. Turn on the unit using the on/off switch.
The unit will automatically carry out a self-
test. Once the self-test is completed the
word “DEUTSCH” flashes“.
5. Use DATA and MASTER to select the ap-
propriate display language (Deutsch, Eng-
lish, Français, Español, Italiano, Português,
Svensk).
The selected setting can be changed at any
time.
6. Press START when the desired language is
displayed.
The letters “MM” flash on the display.
7. Use DATA and MASTER to select the mea-
suring unit (mm, µm or inch) that should be
used to display measured values.
The selected setting can be changed at any
time.
8. Press START when the desired measuring
unit is displayed.
The standard display elements appear (ana-
log scale, display range, current measured
value, the selected measuring unit, and the
probe connection formula).
9. The default connection formula for units with
an inductive module is “+C1 +C2” and for
units with a PE module “+C1”. These settings
can be changed at any time in the catalog of
functions and parameters (see point 12).
10. Set the display range of the scale.
To do this –
– Press the RANGE key.
The current display range for the select-
ed measuring unit is displayed flashing
(e.g. ± 1 mm).
– Use the DATA and MASTER keys to set
the required display range.
– Press START to adopt the set display
range.
11. Set the indicated value of the probe(s) to
zero. To do this, press first the MASTER then
the START keys.
