9. Press START once the desired data transfer
format is indicated. The setting is adopted
and “FORMAT (4.6.2)” is displayed again.
10. If no further settings are to be made in the
catalog of functions and parameters, press
the START key. The standard display ele-
ments appear.
If further settings are necessary, navigate
to the appropriate point of the catalog of
functions and parameters using the ESC,
MASTER, DATA and MENU keys and carry
out the settings as required.
14.3 Selecting the handshake
Specify whether the control signals for data flow
control between asynchronous devices should
be sent over additional lines parallel to the data
lines (hardware handshake) or whether the sig-
nals (embedded in the data stream) should be
sent over the data lines (software handshake).
1. Press the MENU key. The catalog of func-
tions and parameters item “FEATURE (1)” is
displayed.
2. Use the DATA and MASTER keys to select
the setting “SETTING (4)”.
3. Press the MENU key. “DISPLAY (4.1)” is dis-
played.
4. Use the DATA and MASTER keys to select
the setting “COM (4.6)”.
5. Press the MENU key. “PROTOCL (4.6.1)” is
displayed.
6. Use the DATA and MASTER keys to select
“HANDSHK (4.6.3)”.
7. Press the MENU key. The setting that was
last selected flashes.
