14.5 Selecting how to initiate data transfer
Specify whether data is to be transferred either
manually by pressing the DATA key or automati-
cally at the end of the measurement or continu-
ously.
1. Press the MENU key. The catalog of func-
tions and parameters item “FEATURE (1)” is
displayed.
2. Use the DATA and MASTER keys to select
the setting “SETTING (4)”.
3. Press the MENU key. “DISPLAY (4.1)” is dis-
played.
4. Use the DATA and MASTER keys to select
the setting “COM (4.6)”.
5. Press the MENU key. “PROTOCL (4.6.1)” is
displayed.
6. Use the DATA and MASTER keys to select
“SEND (4.6.5)”.
7. Press the MENU key. The setting that was
last selected flashes.
8. Use the DATA and MASTER keys to select
the desired setting. The following settings
are available:
MANUAL Measurement results are trans-
ferred as required by pressing the
DATA key.
AUTOM. Measurement results are trans-
ferred immediately following
each measurement.
SCANN. Measurement data is sent dur-
ing measurement in dependency
of the adjusted transfer rate at a
rate of about 20 values per sec-
ond.
In order to use the AUTOM. and
SCANN. settings,
first one of the following interface
protocols must be selected: ASCII,
M1240, OPTORSS or OPTORSD
and second, “AUTOM.” must have
been adjusted under PROCESS –>
MEASURE -> MEAS.MOD.
9. Press START once the desired setting is in-
dicated. The setting is adopted and “SEND
(4.6.5)” is displayed again.
10. If no further settings are to be made in the
catalog of functions and parameters, press
the START key. The standard display ele-
ments appear.
If further settings are necessary, navigate
to the appropriate point of the catalog of
functions and parameters using the ESC,
MASTER, DATA and MENU keys and carry
out the settings as required.
