3.5 Selecting the number of features/
test results to be displayed
Up to two features can be displayed simultane-
ously on Millimar. However, this is only possible
when static measurements are being carried out.
The number of features that are to be simultane-
ously displayed (either 1 or 2) must be specified
before measuring starts. To do this:
1. Press the MENU key when the standard
display elements are shown. The catalog of
functions and parameters is opened and the
setting “FEATURE (1)” is displayed.
2. Use the DATA and MASTER keys to select
the setting “SETTING (4)”.
3. Press MENU again. The setting “DISPLAY
(4.1)” is displayed.
4. Press MENU again. The setting “FEATURE
(4.1.1)” is displayed.
5. Press MENU again. The setting “1 FEAT.”
is displayed.
6. Use the DATA and MASTER keys to select
the feature display mode. The options are:
1 FEAT. One feature from one static or
dynamic measurement is dis-
played in the bottom line of the
numerical display.
2 FEAT. Two features from one static
measurement are displayed. One
is displayed in the top line of the
numerical display, one in the bot-
tom line.
This, however, is
only possible up to
a certain point. The
Millimar switches
about four times
per second from on
probe channel to
the other and digi-
tizes the encoun-
tered measured
value. Only suitable
for static measure-
ments!
AUTODET From the two features of a static
or dynamic measurement just
one at a time is displayed in the
bottom line of the numerical dis-
play. The display switches from
one feature to the other when
the set area limits are exceeded
or fallen short of.
